Showtec NET-8/5
8 Channel Artnet/Klingnet node, 5p XLR
The Showtec NET-8/3 and NET-8/5 nodes are cutting-edge network routing devices which convert ArtNET to DMX512 and back. A maximum of 4096 channels can be transported over a single CAT5. This makes the NET-8/x suitable for small to large scale events. The NET-8/x embeds a built-in network switch to allow it to be used as a Ethernet repeater as well as 8 isolated DMX-512 universes which can be used as a input or output. All settings can be done by the easy-to-use menu on the graphic display and buttons on the front.
Settings can also be arranged via the web browser possibility, which gives you (remote) access through your computer or laptop and your network. Default login account: Admin, password: Admin.
Settings can also be arranged via the web browser possibility, which gives you (remote) access through your computer or laptop and your network. Default login account: Admin, password: Admin.
- Supports ArtNET, sACN or KlingNET protocol
- 1Gbps data speed
- 8 universes DMX input or output
- High Speed Network in and output
- Web browser connection
Power Supply | 100-240 VAC 50-60Hz |
---|---|
Power Consumption | 20 W |
Power Connector in | ProPower Blue |
DMX Connector | XLR 5P In/Out |
DMX Connector in | XLR 5P |
DMX Connector out | XLR 5P |
Data Connector in | etherCON |
Data Connector out | etherCON |
Length (mm) | 483 mm |
Width (mm) | 143 mm |
Height (mm) | 46 mm |
Installation Depth (excl. connector) | 143 mm |
Weight | 2,2 kg |
Rack Units | 1 U |
IP Rating | IP20(indoor use only) |
Housing | Metal, Plastic |
Colour | Black |
LED Indicators | Operation mode, Power, Signal |
Maximum Ambient Temperature | 40 °C |
Minimum Ambient Temperature | -5 °C |
Minimum Operating Temperature | 0 °C |
Reference Standard | CE |
Included Cables | ProPower Cable |
Control Mode | Art-Net, DMX, PC Software |
Protocols | Art-Net, DMX, Kling-Net, sACN, TCP-IPv4 |
Display | LCD |
Universes | 8 |
