Neutrik 3 pin XLR - Male

  • Male connector with improved locking recess without "window", more stringent housing increases durability
  • Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
  • Boot with polyurethane gland gives high protection to cable bending stresses
  • Colored rings and boots available for coding or identification
  • Sleek and ergonomic design - valuable and handy
  • Rugged zinc diecast shell, longlasting and dependable
  • Internal thread on shell is well protected against any damage
  • Branded with unique hologram - guarantees genuine and authentic Neutrik product

The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.

Specifications:

Electrical:
Capacitance between contacts ≤ 4 pF
Contact resistance ≤ 3 mΩ (inner)
Rated current per contact 16 A
Rated voltage 50 V
Mechanical:
Cabel O.D. 3,5 – 8,0 mm
Wiresize max. 2.5 mm²
Wiresize max. 14 AWG
Wiring Solder contacts
Locking device Latch lock
Material:
Boot Polyurethan
Contacts Brass
Insert Polyamide
Shell Zinc diecast
Shell plating Nickel
Strain relief Polyacetal
Environmental:
Flammability UL 94 HB
Standard compliance IEC 61076-2-103
Protection class IP 40
Solderability Complies with IEC 68-2-20
Temperature range -30 °C to +80 °C
