Active 1020w Subwoofer for live performances and DJs
For smaller venues or temporary sound reinforcement setups that require serious power with a professional edge, look no further than this compact powerhouse. The new DXS12 mkII is equipped with an upgraded 1020W power amplifier producing an impressive 134dB and reaching as low as 42Hz producing clean, clear, heart-stopping bass that defies its lightweight construction.
Try selecting our D-XSUB “BOOST” or “XTENDED LF” low frequency processing settings, turn up the volume, and watch the eyes widen and jaws drop. All this in a small, easy to install enclosure. Listeners will need to search for the source of this much low frequency performance.
12" powered subwoofer with 1020W class-D power amplifier
High-output 12” woofer with a band-pass design cabinet for superb bass response with a maximum 134dB SPL
42Hz-150Hz frequency range is ideal for small to medium-sized applications
Built-in D-XSUB processing allows you to extend the frequency response even lower
Plywood cabinet is durable and acoustically optimized for minimal distortion
Cardioid mode for bass management onstage
Selectable X-OVER (80/100/120 Hz)
M20 and Ø35 mm dual pole sockets
Feel the Power
DXS Series is made for audio engineers and bass fanatics who demand consistent high-quality sound for their live performances or DJ events - even when it's cranked to the maximum SPL.
High-Efficiency 1020W Class-D Amplifiers
The DXS’s high-performance Class-D amplifier is capable of producing up to 1020W of power, and a maximum SPL of 136dB, delivered with exceptional clarity and accuracy. Both the DXS15mkII and DXS12mkII can produce 3dB more SPL than previous models.
Custom Designed Transducer
The high-output woofer of DXS18 features a 4" voice coil magnet and delivers powerful, well-defined, low-frequency bass with minimal distortion. The DXS12mkII and DXS15mkII both feature 2.5" voice coil magnets.
Band-Pass Type Enclosure
All DXS Series enclosures incorporate a band-pass design to reduce unwanted vibrations and noise that could otherwise sabotage your sound. We've also designed a very durable plywood enclosure which, when combined with the band-pass configuration, tested better than the traditional bass-reflex design and reduced distortion considerably, making it possible to achieve a higher SPL.
Durable, Portable, and Road-Ready
Ergonomic and compatible features just made your system setup and transport a whole lot easier.
Rugged coating for superior protection
Enclosure exteriors feature a durable Polyurea coating with extremely high damage resistance to protect the cabinet from scratches, bumps, or severe weather conditions, maintaining a professional appearance for years to come.
Compact and portable design enclosure
Just as impressive as the high output at their disposal is the compact portability and lightweight construction that houses the DXS Series' awesome power. The DXSmkII models in particular have shed 2kg and 3kg compared to their 15” and 12” predecessors respectively, making it easier than ever to load up, set up, or tear down your PA.
Optional Wheel Kit
For more fast and convenient setup of your DXS subwoofers, optional wheels are available, featuring radial ball bearings that ensure smooth running and a rattle-free performance.
Optional Speaker Cover*
The functional speaker covers that protect your speakers from unfavourable weather conditions during operation in outdoor performances, and in dusty and dirty warehouse storage, or the rigors of equipment transport on the road. Trilaminar polyester fabric with an inner cushion protect from impacts. Slits allow easy access to the handles for carriage.
*Covers do not guarantee waterproof protection.
Dual pole socket
For additional flexibility configuring your speakers, the DXS series comes equipped with a dual pole socket that accommodates both 35mm diameter speaker poles and M20 screws.
Features:
12" woofer in a band-pass-style enclosure
Rugged construction with wood cabinet
Compact, lightweight design for smaller performance spaces
Class-D amplifier with 800W continuous output
Onboard DSP with cardioid setting
Specifications:
Speaker Configuration
Active/passive: Active Type: Subwoofer LF driver: 12" MF driver: Not applicable HF driver: Not applicable Power Amplifier class: D Wattage: 800W continuous Mixer/preamp: No Audio Frequency response: 42Hz–150Hz Coverage pattern: Omnidirectional Max SPL: 134dB Inputs XLR: 2 TRS: Not applicable TS: Not applicable RCA: Not applicable SPEAKON: Not applicable Outputs XLR: 2 TRS: Not applicable TS: Not applicable RCA: Not applicable SPEAKON: Not applicable Enclosure Cabinet material: Wood Width: 15.75" Height: 22.32" Depth: 22.44" Weight: 66.1 lb
